Outdoor lcd screen
Yameishi 32inch outdoor lcd display advertising screen digital signage ip67 full waterproof lcd touch screen
-
32inch Free stand outdoor lcd display ip67 full waterproof lcd touch screen advertising digital signage
Features:Fashion appearance: According to customer needs, professional design elegant and stylish shell, diverse styles;Outdoor highlighting: Visible all day under the sun, brightness up to 1500 nit;Smart sensation: The screen brightness is automatically adjusted with the external brightness, saving energy and displaying comfort;Timing backlighting: Supports 10 groups of timing backlighting for easy operation;Intelligent temperature control: intelligent temperature control system to maintain the internal constant temperature and dry environment, prevent fog, condensation phenomenon;Dust and waterproof: The entire confidential closed design prevents foreign dust and water from entering the interior and reaches the IP55 standard;Sun protection explosion-proof: the shell is galvanized steel or stainless steel, after the paint, waterproof sunscreen, explosion-proof professional surface technology processing;Anti-reflection and anti-reduction: The front of the product adopts imported anti-glare glass, which can effectively increase the internal light projection, reduce the reflection of external light, make the LCD display image color, more vivid and bright;High reliability: Through a reliable hard disk self-check and repair mechanism, the player supports more than 10,000 forced power-off and power-off and on-off without damage to the file and reliable broadcast;Easy to use: The player does not require special network personnel for maintenance. The player can be started automatically, automatically shut down, self-managed, and easy to use.
Structural performance:1. The shell material is fully galvanized steel plate body, the outer surface is imported with metal paint, anti-magnetic, anti-static, imported waterproof material, the whole machine adopts IP55 waterproof, outdoor all-weather waterproof and dustproof, anti-theft, explosion-proof design;2. Strict electrical protection: leakage, overload, overvoltage protection, lightning protection device, over temperature protection, etc.;3. Sound: Double channel, stereo surround power amplifier system, output power 8 ohm 2 × 10W;4. Working environment design standard +55 ° ~ -30 °, cooling using a stable and reliable air-cooled structure heat dissipation plus aluminum military-grade heat sink substrate;5. Tempered glass: 6mm AR tempered laminated glass;6. The whole system adopts modular design principles, sustainable and maintainable design;7. Machine fixing method: use screw column from the ground, insert it to the bottom of the machine and fix it with nut;8. Excellent light perception system: The ambient light brightness is automatically adjusted to control anti-glare, and it can meet the clear image display under strong sunlight.
Product advantages:1. High-brightness LED-backlit LCD screen with lumens of up to 1500/2000/3000nits, still visible in the sun environment;2. The unique liquid crystal substrate can be processed at a wide temperature of -30°C-60 degrees Celsius, and it can be quickly started and clear image display in low temperature environment;3. The United States imports anti-UV infrared heat insulation heat-resistant high-transmission AR glass, the thickness is only 6-10mm;4. Unique military heat dissipation technology, built-in high-efficiency heat dissipation device and high-quality fan group, multi-duct cooling structure and filter dust-proof system;5. Intelligent sensitization, automatically adjust the screen brightness according to the surrounding environment, so as to achieve the best visual effect, energy saving and reduce the aging degree;6. Real bright and vivid color display, up to 1920 x 1080 resolution;7. Outdoor rain-proof heat-resistant metal casing and waterproof and dust-proof casing structure in outdoor stormy environments;8. Built-in stand-alone (network) player board, industrial computer (optional), interactive multi-touch (optional);Web version features:1. The main chip adopts the series products of American Sigma Designs Semiconductor Company, and the 1920x1080 high-definition video decoding image quality is excellent, supporting the mainstream HD video packaging format;2. Using 500+333M main frequency MIPS+FPU and hard decoding, it perfectly supports 1920x1080P HD video files, and supports multiple split screen playback, rss, PDF, slide files and TXT water subtitles, perfect for displaying multimedia digital signage for you. charm;3. Low-cost operation and maintenance and high-efficiency program release and update: This product supports LAN, WIFI and 3G flexible network operation, and can control every digital signage of the network anytime, anywhere in the world.4. Support large-capacity SATA hard disk, SD card storage media and USB2.0 interface, so that your machine can update programs through U disk efficiently without network connection;Technical Data Sheet
Stand alone versionWeb network versionModel:Model:Main ChipOUTDOOR seriesMain ChipAndroid DesignsInterface1xUSB2.0,1xCF,1xSDInterface1xUSB2.0,1xSATA,1xSD,CVBSStorage mediumU disk,CF card,SD cardStorage mediumClass 6/10 SD card SATA DOM,hard diskVideo formatMPG,MPG-1,MPG-2,MPG-4,AVI,MP4,DIV,TS,TRP,MKV,WMV,RM,RMVBVideo formatMPG,MPG-1,MPG-2,MPG-4,AVI,MP4, TS,MKV,WMV,etcMax resolution1920*1080Max resolution1920*1080Picture formatJPEG,PNG,BMPPicture formatGIF,JPEG,PNG,BMPAudio output2x15WAudio output2x15WMaximum frame rate30frm/sAudio formatMP3,24bit linear PCM7.1Audio sampling rate32KHZ,44.1KHZ,48KHZ,96KHZManagement softwareOperating environment:windows 2003/xp/win7Bit rate32kbps-384kbpsOther formatPDF/RSSNews/Weather forecast/PPTMaximum color depth24bitNetworking methodRJ45 interface,wifi(optional),3G(optional)Maximum streamUSB2.0 device:30MB/SProgram update methodNetwork remote update, U disk updateProduct functionSupport menu rotation, OSD multi-language, power-on automatic loop playback, breakpoint memory, commercial insertion, time switch, time-lapse volume, logo, water subtitles, USB program update program, automatic generation of play log, support video, picture, picture + music, mixed mode.
Display modeHorizontal / vertical screen, full screen / arbitrary split screen
Program downloadUsing FTP protocol, regular download, automatic downloadProgram upgradeRemote upgrade, remote controller upgradeTimer switchSupport for any time periodOther functionTime-sharing volume, background music, scrolling subtitles, logo, background image, remote power on/off, streaming media, interstitial timing playback, multiple program style loop playback, timed broadcast TV.
Panel parameterPanel type32”LED PanelDisplay sizeAspect ratio16:9Backlight typePatented LED backlight modular component + constant current source drive component
Resolution1080*1920Display colour16.7MBrightness1500cd/m2 Meets clear image display in strong sunlight
Contrast3500:1Viewing angle178°(H) / 178°(V)Response time5msColor systemPAL/NTSC/SECAMLifetime60000 hoursHeat dissipation parameterSmart fan coolingAutomatically adjust air volume according to temperature (EBM centrifugal fan cooling)
Max input power WAC 100WWorking environment temperature range-35℃--------+55℃Noise Db(A)<55dBProtection levelIP55Lifetime50000HMTBF(mean time between failures)40000Hworking environmentWorking temperature-35℃~55℃storage temperature-35℃~60℃Working humidity10%~90%Storage humidity10%~90%Othercooling methodPatented heat dissipation structure combination + aluminum military grade heat sink substrate
Protective glassspecial 6mm AR laminated glassAppearance colourSilver, gray, whiteFrame materialGalvanized steel plate + outdoor special paintProduct certificationISO9001,3C,FCC,ULNet weight89KgPower inputAC100V~240VPower≤280WStandby power≤3W
