Enclosure full outdoor Aluminum or stainless-steel enclosure or Zinc; All electronic component in box, the controller and LCD plate with 3layer glue to protect it (anti-mould, anti-humidity, anti salt-fog)

Powder coating: Akzo powder, anti-graffiti and anti salt-fog, lifetime longer than 10 years.

Digital display screen rugged housing all RAL color available

Built-in configuration: over-voltage protection, Class A EMC Heat dissipation Shortcut protection, PG09, PG B connector. In this way, the life-span of our digital totem will be 8-10 years.

Protective glass/durability 3+3 laminated tempered anti-reflection glass, UV 99% Protection, reach to IK10, anti-vandalism anti-glare or anti-reflective glass.

High Brightness: 3000nits to 3500nits to 4000nits, AVLink digital signs sunlight readable

Shenzhen Yameishi bright screens equipped with automatic brightness control, with this sensor, brightness could suit the environment perfectly.

Shenzhen Yameishi advertising player LCD display wide viewing Angle 178/178

External digital monitor 1920*1080 2K and 3840*2160 4K resolution available.

Wide operating temperate in outdoor monitor: with heater to suit down to -40 degree in Russia such cold environment, +60 degree operating temperature in Dubai such hot area.

Product lifetime: more than 60000hours

IP level: IP55, IP65, IP66, IP67 available

IK10 level

Certification: CE, FCC, RoHS, IP65 rated.

Could be freestanding, wall-mounted, roof-mounted, embedded application.

Could be landscape, portrait orientation.

Shenzhen Yameishi passenger information display could with Air conditioner or fans cooling system

Screen	Sizes	32”	43”	49”	55”	65”	75”	86”
	Backlight type	LG /AUO/BOE
	Display dimension	697*392	941*530	1074*604	1209*680	1428*803	1650*928	1895*1065
	Brightness	2000nits	2500nits	3000nits
	Resolution	1920*1080	1920*1080	1920*1080	1920*1080	1920*1080	3840*2160	3840*2160
	Display scale	16:09
	Contrast	1900/5/24 20:01
	Backlight type	6S
	Viewing angle	178°(H)/178°(V)
	Light type	Vertical LED
	Life span	60000hours
Control system	Intelligent dimmer	YES
	Intelligent temperature	YES
voltage	Power input	AC220/110V±10%，50/60 HZ
	Rated power	130W	180W	260W	300W	400W	600W	800W
Outer Shell	Protection level	IP66
	Shell material	Aluminium profile
	Shell life	Eight years
	Glass types	AR Antireflection glass
	Product size	472*777*98	610*1021*98	684*1154*98	763*1293*98	883*1508*98	1028*1750*98	1115*1995*98
	Weight(kg)	35kg	45kg	60kg	65kg	90kg	120kg	160kg
Service Environment	Service Environment	All outdoors
	Use of temperature	-30℃~+80℃
	Ambient humidity	5%~98%

Item	Working Environment
Working temperature	-20"C~ 70"C
Storage temperature	-10"C~ 60‘C
Working humidity	5% ~ 100%
Storage humidity	5% ~ 90%
Noise	<58dB
Protection level	IP66
Frame color	Black/ white/ gray/ red/ silver
Power input	AC220/110Vt10%, 50/60 HZ
Rated power	130W(32") 180W(43") 240W(46") 260W(49") 300W(55") 400W(65")
Weight	35kg 45kg 55kg 60kg 65kg 90kg
